A video of this procedure is available at YouTube: https://www.youtube.com/playlist?list=PLYV5R7hVcs-
CTkyVDu-5Lhy1r9G-4PQGl
.
Procedure
Step 1. Loosen the two thumbscrews located on the front of the server to disengage it from the rack.
Rack front
Figure 17. Disengaging server from the rack
1
Latches
2
Thumbscrew
Step 2. Hold the mounting ears on the front of the server; then, slide the server all the way out until it stops.
46
ThinkSystem SR645 V3 User Guide
