Parameter setting with the XT EMZ9371BC keypad
Commissioning example in V/f characteristic control mode
6.3
6.3.1

6.3−4
EDSVF9383V EN 7.1−04/2012
NoteSwitch−on sequence
28. The drive is running now CW rotation:
X5/E1 = HIGH and X5/E2 = LOW
CCW rotation:
X5/E1 = LOW and X5/E2 = HIGH
If the drive does not start, press  in
addition
(see chapter "Commissioning" ®
"Acceleration, deceleration, braking,
stopping")
 Note!
In the "Diagnostic" menu you can monitor the most important
drive parameters
