Configuration
Function blocks
Master frequency processing (DFSET)
8
8.2
8.2.5

8.2−21
EDSVF9383V EN 7.1−04/2012
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0536 −32767 {1} 32767
Function block DFSET
l Display of the signals linked in
C0521, C0522 and C0523

8.2−18
1 DIS: VP−DIV
2 DIS: RAT−DIV
3 DIS: A−TRIM
C0537 DIS: N−TRIM −199.99 {0.01 %} 199.99 Function block DFSET
l Display of the signal linked in
C0524
C0538 0 1
Function block DFSET
l Display of the signals linked in
C0525, C0526 and C0527
1 DIS: 0−pulse
2 DIS: RESET
3 DIS: SET
C0539 DIS: IN −6000 {1 rpm} 6000 Function block DFSET
l Display of the signal linked in
C0520
C0546 Min inc/rev 1000 1 {1 inc.} 2147483647 Masking of the touch probe signal,
function block DFSET
l Suppressing interference
pulses at X5/E4 (actual pulse of
touch probe signal)
l The size of the masking
window between two actual
pulses is set

8.2−18
