Lenze EVS9321-Ex System Manual

Configuration
Function blocks
Master frequency processing (DFSET)
8
8.2
8.2.5

8.2−20
EDSVF9383V EN 7.1−04/2012
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0529 Multip offset 1 −20000 {1} 20000 Offset multiplier, function block
DFSET
l Multiplier for the phase offset
(C0252)

8.2−18
C0530 DF evaluation 0
0 with factor With gearbox
factor
Master frequency evaluation,
function block DFSET
l Evaluation of the setpoint
integrator
1 no factor Without gearbox
factor
C0531 Act 0 div 1 1 {1} 16384 Actual zero pulse divisor, function
block DFSET
C0532 0−pulse/TP 1
1 0−pulse Index pulse
Zero pulse / touch probe, function
block DFSET
l Zero pulse of the feedback
system or touch probe
2 Touch probe Touch probe
C0533 Vp denom 1 1 {1} 32767 Gain factor of denominator V
p
,
function block DFSET
C0534 0 pulse fct 0
Zero pulse function, function
block DFSET
l Synchronising the drive

8.2−18
0 inactive Inactive
1 Continuous Continuous
synchronisation,
correction in the
shortest possible
way
2 Cont. switch Continuous
synchronisation,
correction in the
shortest possible
way
After a LOW−HIGH signal to
DFSET−0−pulse, the zero track is
synchronised once
10 Once, fast way One−time
synchronisation,
correction in the
shortest possible
way
11 Once, CW One−time
synchronisation,
correction in
direction of
rotation to the
right
12 Once, CCW One−time
synchronisation,
correction in
direction of
rotation to the left
13 Once, 2*0−pulse One−time
synchronisation,
correction is
detected from
setpoint pulse and
actual pulse and
corrected to the
corresponding
direction
C0535 Set 0 div 1 1 {1} 16384 Desired zero pulse divisor,
function block DFSET

8.2−18
