Configuration
Code table
8
8.5
8.5−2
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0005
Signal CFG
Selection of the basic
configuration
1000
0 Common Modified basic
configuration
The first two digits indicate the
predefined basic function, e. g.:
l 01xxx: Speed control
The third digit indicates additional
functions:
l xx0xx: No additional function
l xx1xx: Brake control
l xx2xx: Setpoint selection via
motor potentiometer
l xx3xx: PID controller
l xx4xx: Mains failure control
l xx5xx: Setpoint selection via
master frequency
l xx6xx: Gearbox factor − analog
trimming
l xx7xx: Gearbox factor − digital
trimming
l xx8xx: Master frequency ramp
function generator
The fourth digit indicates the
predefined voltage source for the
control terminals:
l xxx0x: External supply voltage
l xxx1x: Internal supply voltage
The fifth digit indicates the
predefined device control
l xxxx0: Terminal control
l xxxx1: RS232, RS485 or optical
fibre
l xxxx3: INTERBUS or
PROFIBUS−DP
l
100 CFG: emty All internal
connections are
removed
1000 Speed mode Speed control
2000 Step mode Step control
3000 Lead screw Traversing control
4000 Torque mode Torque control
5000 DF master Digital frequency
master
6000 DF slv bus Master frequency
slave (bar)
7000 DF slv cas Digital frequency
slave (cascade)
8000 Dancer ctrl e Dancer position
control with
external diameter
measurement
9000 Dancer ctrl i Dancer position
control with
internal diameter
measurement
C0006
Op mode 5
Selection of the operating mode
for the motor control
1 vector ctrl Vector control
without or with
speed feedback
In case of the first selection enter
the motor data and identify them
with C0148.
6.8−8
5 V / f V/f characteristic
control
Commissioning without
identification of the motor data is
possible
l Advantage of identification
with C0148: Improved smooth
running at low speeds
6.8−4
C0009 LECOM address 1 1 {1} 99 LECOM controller address
l Bus device number when
operated via interface
l 10, 20 ... 90 reserved for
broadcast to device groups
with RS232, RS485, optical
fibre
