Lenze EVS9321-Ex System Manual

Configuration
Code table
8
8.5

8.5−6
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0039 −36000 {1 rpm} 36000
JOG setpoints for the speed
setpoint conditioning, function
block NSET
l Parameter setting of the fixed
speeds (JOG setpoints)
l Activation via binary coding of
digital input signals in
C0787/1 ... C0787/4
l For coding see description of
function block NSET
See System
Manual
(extension)
1 JOG set−value 1500
2 JOG set−value 1000
3 JOG set−value 500
4 JOG set−value 200
5 JOG set−value 100
6 JOG set−value 50
7 JOG set−value 25
8 JOG set−value 10
9 JOG set−value 5
10 JOG set−value 0
... ... ...
15 JOG set−value 0
C0040 Ctrl enable 0
Controller enable
l Controller can only be enabled
if X5/28 = HIGH
 6.4−1
0 Ctrl inhibit Controller inhibited
1 Ctrl enable Controller enabled
C0042 DIS: QSP
Quick stop
l Display only

8.2−25

8.2−40
0 QSP inactive Quick stop is not active
1 QSP active Quick stop is active
C0043 Trip reset 0
0 no/trip reset Reset actual error
1 trip active There is a TRIP error
C0045 DIS: act JOG
0 Nset active Nset is active
Active JOG setpoint for the speed
setpoint conditioning, function
block NSET
l Display of the activated fixed
speed
See System
Manual
(extension)
1 JOG1 JOG setpoint 1
2 JOG2 JOG setpoint 2
... ... ...
15 JOG15 JOG setpoint 15
C0046 DIS: N −199.99 {0.01 %} 199.99 Main setpoint for the speed
setpoint conditioning, function
block NSET
l Read only
C0049 DIS: NADD −199.99 {0.01 %} 199.99 Additional setpoint, function
block NSET
l Read only
See System
Manual
(extension)
C0050 MCTRL−NSET2 −100.00 {0.01 %} 100.00 Speed setpoint, function block
MCTRL
l Display of the speed in [%] of
C0011

8.2−25

8.2−40
C0051 MCTRL−NACT −36000 {1 rpm} 36000 Actual speed value, function block
MCTRL
l Read only

8.2−25

8.2−40
C0052 MCTRL−Umot 0 {1 V} 800 Motor voltage, function block
MCTRL
l Read only
l MCTRL−VACT = 100 % = C0090

8.2−25

8.2−40
C0053 UG−VOLTAGE 0 {1 V} 900 DC−bus voltage, function block
MCTRL
l Read only
l MCTRL−DCVOLT = 100 % =
1000 V

8.2−25

8.2−40
