Configuration
Code table
8
8.5

8.5−7
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0054 Imot 0.0 {0.1 A} 5000.0 Actual motor current, function
block MCTRL
l Read only
l MCTRL−IACT = 100 % = C0022

8.2−25

8.2−40
C0056 MCTRL−MSET2 −100.00 {0.01 %} 100.00 Read only. The output signal
depends on the operating mode:
l Current motor current in case
of V/f characteristic control,
function block MCTRL1
l Torque setpoint in case of
vector control, function block
MCTRL2

8.2−25

8.2−40
C0057 Max Torque 0 {1 Nm} 5000 Maximum possible torque of the
drive configuration
l Display only
l With V/f characteristic control
depending on C0022, C0086,
C0088
l With vector control depending
on C0022, C0086, C0088,
C0091
C0058 MCTRL−FACT −600.0 {0.1 Hz} 600.0 Output frequency
l Display only
l MCTRL−FACT = 100.0 % =
1000.0 Hz

8.2−25

8.2−40
C0059 Mot pole no. 1 {1} 50 Pole pair number of the motor
l Display only
C0061 Heatsink temp 0 {1 °C} 100 Heatsink temperature
l Read only
l If the temperature of the
heatsink > 85 °C, the controller
sets TRIP OH
l Early warning is possible via
OH4, temperature is set in
C0122
See System
Manual
(extension)
C0063 Mot temp 0 {1 °C} 200 Motor temperature
l Read only
l Monitoring of the motor
temperature must be
activated.
l KTY at X8/5, X8/8:
– At 150 °C, TRIP OH3 is set
– Early warning is possible via
OH7, temperature is set in
C0121
l PTC, thermal contact at T1, T2:
– Release sets TRIP or
warning OH8

8.2−25

8.2−40
C0064 Utilization 0 {1 %} 150 Device utilisation I×t
l Read only
l Device utilisation of the last
180 s operating time
l C0064 > 100 % triggers
warning OC5
l C0064 > 110 % limits the ouput
current of the controller to
67 % of the maximum current
in C0022

8.2−25

8.2−40
C0066 MOTOR LOAD 0 {1 %} 250 Motor load I
2
×t 
8.2−25

8.2−40
