Configuration
Code table
8
8.5
8.5−9
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0082
Mot Rr à 0.0000 {0.0001 W} 65.5350 Motor rotor resistance
à Value is determined by motor
parameter identification from
C0087, C0088, C0089, C0090
and C0091
l Selection of a motor in C0086
sets the corresponding rotor
resistance value
6.6−1
6.6−15
C0084
Mot Rs à 0.00 {0.01 mW} 100000.
00
Motor stator resistance
à Value is determined by motor
parameter identification
(C0148, C0149)
6.6−1
6.6−15
C0085
Mot Lss à 0.00 {0.01 mH} 6553.50 Motor leakage inductance
à Value is determined by motor
parameter identification
(C0148, C0149)
6.6−1
6.6−15
C0086
Mot type à Motor selection list Motor type selection
à depending on the controller
used
l Motor selection in C0086 sets
the corresponding parameters
in C0021, C0022, C0081,
C0087, C0088, C0089, C0090,
C0091
6.6−1
C0087
Mot speed à 50 {1 rpm} 36000 Rated motor speed
à depending on C0086
l Motor selection in C0086 set
the corresponding rated motor
speed in C0087
l Change of C0087 sets
C0086 = 0
6.6−1
C0088
Mot current à 0.5 {0.1 A} 1000.0 Rated motor current
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
current in C0088
l Change of C0088 sets C0086 =
0
6.6−1
C0089
Mot frequency à 10 {1 Hz} 5000 Rated motor frequency
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
frequency in C0089
l Change of C0089 sets
C0086 = 0
6.6−1
C0090
Mot voltage à 0 {1 V} 1000 Rated motor voltage
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
voltage in C0090
l Change of C0090 sets C0086 =
0
6.6−1
C0091
Mot cos phi à 0.50 {0.01 } 1.00 Motor cos j
à depending on C0086
l Motor selection in C0086 sets
the corresponding motor cos j
in C0091
l Change of C0091 sets
C0086 = 0
6.6−1
