Configuration
Code table
8
8.5
8.5−10
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0092
Mot Ls à 0.00 {0.01 mH} 6553.50 Motor stator inductance
à Value is determined by motor
parameter identification from
C0088, C0089, C0090 and
C0091
à Motor selection in C0086 sets
corresponding stator
inductance value in C0092
6.6−1
C0093 Drive ident
Controller identification
l Read only
0 Invalid Defective power section
1 None No power section
14
...
20
9335VC 400V
...
9383VC 400V
Display of the controller used
21
...
28
9334VC 500V
...
9383VC 500V
9321
...
9333
9321 VC
...
9333VC
C0094 Password 0 0 {1} 9999 Password
l C0094 = 1 ... 9999: Free access
to the user menu only
7.2−9
C0095
Mot Io à 0.0 {0.1 A} 1000.0 Motor magnetising current
à dependent on C0086, C0088
and C0091
l Change of C0086 sets C0095 to
the Lenze setting
l Change of C0095 sets
C0086 = 0
6.6−1
C0096
0 no protection No password
protection
Parameter access protection
l Extension of the access
protection for AIF bus systems
and CAN with activated
password in C0094
l All codes in the user menu can
continued to be accessed.
1 R protection Read protection
2 W protection Write protection
3 R/W protection Read/write
protection
1 AIF protect. 0 Parameter access protection AIF
2 CAN protect. 0 Parameter access protection CAN
C0099 S/W version
x.y
Software version
l Read only
x
y
Main version
Subversion
