Configuration
Code table
8
8.5
8.5−14
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0144
OH switch 1
0 Switch off Switch−over is not
active
Temperature−dependent
switching frequency reduction
l If the heatsink temperature set
in C0122 is reached (warning
OH4), the controller switches
to 2 kHz
1 Switch on Switch−over is
active
C0145
select ref May only be changed by Lenze
service personnel!
C0146 fly current May only be changed by Lenze
service personnel!
C0147 fly dt−f May only be changed by Lenze
service personnel!
C0148
ident run 0
0 WRK
stop
Ready
Motor data identification
1. Inhibit controller, wait until
drive has stopped
2. Enter the correct values of the
motor nameplate into C0087,
C0088, C0089, C0090, C0091
3. Set C0148 = 1, confirm with
"
4. Enable controller
The identification
– starts, goes off. The
motor "whistles" but does
not rotate!
– lasts approx. 1 ... 2 min
– is completed when is lit
again
5. Inhibit controller:
6.6−15
1 WRK run Start identification
C0149
Auto ident 0
0 Id
inactive
Automatic identification is
inactive
Automatic motor data
identification
1. Inhibit controller, wait until
drive has stopped
2. Enter the correct values of the
motor nameplate into C0087,
C0088, C0089, C0090, C0091
3. Set C0149 = 1, confirm with
"
4. Enable controller
The identification
– starts, goes off. The
motor "whistles" but does
not rotate!
– lasts approx. 1 ... 2 min
– is completed when is lit
again
5. Inhibit controller:
6.6−15
1 Id active Automatic identification is
active
l The identification starts
automatically after
controller enable
l After a faulty
identification, the process
is restarted after TRIP
RESET or mains switching
and subsequent
controller enable
C0150 Status word
Bit00 — Bit08 Status code
Read only
Decimal status word for
networking via automation
interface (AIF)
l Binary interpretation indicates
the bit states
See System
Manual
(extension)
Bit01 IMP Bit09 Status code
Bit02
— Bit10 Status code
Bit03
— Bit11 Status code
Bit04
— Bit12 Warning
Bit05
— Bit13 Message
Bit06
n = 0 Bit14 —
Bit07
CINH Bit15 —
