Lenze EVS9321-Ex System Manual

Configuration
Code table
8
8.5

8.5−15
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0151 DIS: FDO (DW) Read only
l Free digital outputs (FDO)
l Hexadecimal representation of
the digital output signals
configured in C0116
l Binary interpretation indicates
the bit states
See System
Manual
(extension)
C0155 Status word 2
Bit00 Fail Bit08 R/L
Display only
l Binary interpretation indicates
the bit states
Bit01 M
max
Bit09 —
Bit02
I
max
Bit10 —
Bit03
IMP Bit11 —
Bit04
RDY Bit12 —
Bit05
CINH Bit13 —
Bit06
TRIP Bit14 —
Bit07
Init Bit15 —
C0156

 Selection list 2
Configuration of digital input
signals of function block STAT
l Input signals are output as
status messages in C0150, AIF
status word and CAN1 status
word
See System
Manual
(extension)
1 CFG: STAT.B0 2000 DCTRL−PAR*1−O
2 CFG: STAT.B2 5002 MCTRL−IMAX
3 CFG: STAT.B3 5003 MCTRL−MMAX
4 CFG: STAT.B4 5050 NSET−RFG I=O
5 CFG: STAT.B5 10650 CMP1−OUT
6 CFG: STAT.B14 505 DCTRL−CW/CCW
7 CFG: STAT.B15 500 DCTRL−RDY
C0157 0
1
No status message
Status message is output
Digital status signal of function
block STAT
l Display of the signals linked in
C0156
1 DIS: STAT.B0
2 DIS: STAT.B2
3 DIS: STAT.B3
4 DIS: STAT.B4
5 DIS: STAT.B5
6 DIS: STAT.B14
7 DIS: STAT.B15
C0161 Act trip Display of history buffer "Active
fault"
l Keypad: LECOM error number
See System
Manual
(extension)
C0167 Reset failmem 0
0 Ready
Clear history buffer
l Active fault messages are not
cleared
See System
Manual
(extension)
1 Clear history buffer
