Page 65
©2013 Technical Marine Service, Inc. LC-100 V2.97
Programming Worksheet
Tank:_____________________ Service:_____________ Address:_____
Password:
Configuration Worksheet Explained
This section provides a description of the Programming Worksheet. This worksheet allows
the user to analyze the parameters associated with a given tank and to collect the data in a
format that follows the programming procedure. The worksheet below contains explanations
of the functions of the data, and guidance in the program setup. Do not fill in this
worksheet; it is for explanation purposes only.
On page 70 you will find a two page Programming Worksheet. Make enough copies of the
Programming Worksheet so you will have one full copy for each LevelCom 100. Your
worksheets serve as the record of your LevelCom 100 installations and should be kept on
file.
In a pocket inside the back cover you will find the Configuration Flow Chart. This is a “tree”
chart that documents the program flow path. Referencing this chart will help you to
understand the operation and flexibility of the LevelCom 100.
Display Setup
This section establishes the display functions of the LevelCom 100. Select the depth,
volume and weight units desired. If ullage is to be displayed in any of the units selected then
also check ullage. Display Units determines the units that will be displayed by the LevelCom
100. In operation, pressing the ESCAPE key will scroll the LevelCom 100 display to the next
display parameter.
For example, let’s say you have selected Feet & Inches, Barrels and Long Tons as units of
measure and have selected Volume Units for display. By pressing the ESCAPE key, the
instrument will momentarily display L TONS and then indicate the tonnage on the digital
display. Pressing ESC again will bring up FEET INCHES followed by the depth. This will
remain on the display for approximately 20 seconds and will automatically return to the
normal volume display in Barrels.
If the tank service is changed, i.e. fuel oil/ballast, simply select the new Display Unit and
modify the Specific Gravity as necessary. The LevelCom 100 will automatically convert the
parameters.
