Page 69
©2013 Technical Marine Service, Inc. LC-100 V2.97
Hi-Hi: Setpoint_______ Hysteresis________
Hi: Setpoint_______ Hysteresis________
Lo: Setpoint_______ Hysteresis________
Lo Lo: Setpoint_______ Hysteresis_______
Sample Timing ___ Specific Gravity (Manual)___ Purge Now___ Display Units___
Display Mode____ Relay 1 Control Setpoints___ Relay 2 Control Setpoints___
Alarm Setpoints___
hysteresis, the Hi-Hi alarm will activate on a climbing level at 10'. When the level drops, the
alarm will clear at 9' 6.0".
Hi and Hi-Hi alarms are adjustable between Bubbler to Bottom and 110% Max Depth. This is
to allow the user to configure the program to tanks that are often “pressed” or purposely
overflowed (e.g. vessel double-bottom fuel tanks).
Lo alarms are adjustable between Bubbler to Bottom and Max Depth
Hot Menu
The LevelCom 100 is programmed with a “Hot Menu” which allows the user to access and
change certain program features and parameters without the need to enter into the complete
program. Use discretion in setting up the “Hot Menu”, as these selections will not be
password protected
