Lexmark X422 - Page 115

Replacing the pick roller assembly and the separator pick roller
115
Maintenance
10 Align the tabs on each side of the separator pick roller with the slots and slide it into place.
11 Align the tabs on the cover with the slots and firmly press it into place.
12 Remove the new pick roller assembly from its packaging.
