Lexmark X46X Series Service Manual

Diagnostic aids 3-35
7014-xxx
3. To test the paper present sensor, push back on the actuator (A). If the sensor is functioning, the 0 next to
the P on the display will change to 1.
4. To test the flatbed cover closed sensor, lift the flatbed cover. The 0 next to the F will change to 1. Also
check the actuator (B) to ensure it is functiong properly.
A
A
B
