Lexmark X46X Series - Page 258

4-96
7014-xxx
16. Remove the screw (C) securing the left flatbed stop to the top of the print engine frame.
17. Remove the screw (D) securing the right flatbed stop to the top of the print engine frame.
18. Lower the flatbed and ADF to the down position.
B
C
D
