Parts catalog
7-27
7510
Assembly 25: T
oner Dispense
Asm-
index
Part
number
FRUs/
mach
Units/
FRU
Description
1
40X3740
1
1
K to
ner dispense assembly
2
40X3739
1
1
C toner di
spense assembly
3
40X3738
1
1
M to
ner dispense assembly
4
40X3737
1
1
Y to
ner dispense assembly
5
40X3741
1
1
CMYK to
ner add motor assembly
6
40X0636
4
1
Sen
sor (RFID toner cartridge)
728
730
