7-86
MFP Service Manual
7510
Assembly 63: TTM me
dia tray 4 transport
Asm-
index
Part
number
FRUs/
mach
Units/
FRU
Description
1
40X3838
1
1
T
TM tray 4 media transport assembly
2
40X3679
1
1
M
edia feed unit assembly
3
40X3841
1
1
TTM tray 4 low
er media guide
4
40X3840
1
1
T
TM tray 4 upper media guide
5
40X3694
2
1
Sen
sor (tray 4 feed-out)
3
5
2
4
1
787
789
