Lexmark X945 - Tray 3 or 4 Media Tray Assembly

To Next Page

To Previous Page

1-60 Service Manual

7510

Tray 3 or 4 media tray assembly

Rear lift cables

Rear media guide

Bottom plate

F/R lift cable

F/L lift cable
