7-64 MFP Service Manual

7510

Assembly 50: 1TM feed unit assembly

Asm-

index

Part

number

FRUs/

mach

Units/

FRU

Description

1 40X3677 3 1 Switch (media size)

2 40X3676 6 1 Media tray slide

3 40X3675 3 1 Media tray catch

4 40X3678 3 6 Media tray assembly kit

• Media tray assembly

• #1 label

• #2 label

• #3 label

• #4 label

• Instruction label

5 40X3679 1 1 Media feed unit assembly
