LG V-NET AC Smart II Advanced Control Smart User Manual

1. AC SMART II Introduction
AC Smart
1-3
AC Smart is composed in the following shape.
Backlight button and keyboard button
Control panel
Stylus pen and
stylus pen holder
124mm
USB PORT (only for SVC & Spare)
RESET BUTTON
Option card slot
(reserved)
40mm
217mm
AC SMART II exterior
Note: Using the external button to compensate the screen
The screen compensation function can be executed by pressing the keyboard button at the top of
the AC Smart and then the backlight button.
When it is hard to execute the screen compensation function by the touch screen, you can use this
method.
Caution: USB Port and Option card slot
USB port is only for SVC and development, therefore USB port is not available to
general users.
Option card slot is reserved for the future model.

LG V-NET AC Smart II Advanced Control Smart Specifications

General

Brand	LG
Model	V-NET AC Smart II Advanced Control Smart
Category	Air Conditioner
Language	English
