AC Smart
9-10
Zone Management
Zone is the logical set of Groups configured around a location of unit function etc. Zone can be
composed of several Groups. When executing a specific control command to the specific Zone, all the
Groups included in the Zone will execute the same control command.
Creating new zone
To create a new zone, proceed in the following order.
1. Select the 'System' menu from the menu of AC Smart. When you select the 'System' menu, the
following screen is displayed. To create a new zone, click on 'AC Smart', which is the highest node
of the 'System tree'. List of unregistered units is displayed in 'Unregistered unit' on the right side of
the screen.
When you click on the highest node
unregistered unit is displayed
Reference: When the unregistered unit is not shown
When you initially execute AC Smart and have not executed the process of registering the unit,
unregistered unit will not be displayed. Proceed after executing registering unit process. If you
cannot see the unregistered unit while using AC Smart, all units are already included in specific
zone and group.
9. System Menu
To Next Page
