AC Smart
5-11
Creating schedule pattern
Schedule pattern refers to a certain operation of unit (Indoor unit, Ventilator, On/Off unit, AWHP unit)
repeated for each day or week.
Schedule pattern wizard is the process of configuring the operation of the unit in weekly or daily
pattern. The pattern created through the schedule pattern wizard can be applied to the Group as a
schedule through schedule wizard to be described in the next section.
Schedule pattern wizard can be configured through total of 4 steps as shown below.
1. Select schedule pattern type 2. Add/Edit schedule pattern
3. Enter schedule pattern name 4. Edit schedule pattern
5. Schedule menu
