Installation/Owner's Manual
9-7
Item Description
Enter the type of unit.
- Air conditioner, Ventilator, Eco V DX, On/Off Device, AWHP
Enter the name of the unit. You can enter up to 20 characters.
Enter the physical address of the unit. The physical address value is between
00 and FF, and cannot be duplicated.
Enter the model of the unit. You can enter up to 20 characters
Enter the maximum power consumption value. The power consumption must
not exceed the set value. You can enter up to 5 digits.
Type
Unit name
Address
Model
Capacity
3. Added unit information is displayed in the table. Repeat the process in the same method to register
all units to add.
To save the registered unit, click on the [OK] button.
To apply to system
click on [OK] button
9. System Menu
