LSIS sv-ig5a User Manual

11-10
2.2) Inverter Control Area Parameters (Reading and Writing Available)
Note 1) Writing available, when frequency command is communication.
Note 2) Writing available, when run command is communication mode.
Note 3) Writing available, when PID Reference (H57 = 4) is communication mode.
Note 4) Writing available, PID Feedback(H50 = 2) is communication mode.
Address
Parameter
Scale
Unit
Allotment for Bits
0x320
Digital input
Information
-
-
B15 ~ B8 : Reserved
B7 : P8
B6 : P7
B5 : P6
B4 : P5
B3 : P4
B2 : P3
B1 : P2
B0 : P1
0x321
Digital output
information
-
-
B15 ~ B2 : Reserved
B1 : MO
B0 : 3ABC
0x0323
Select motor
-
-
0 : First motor, 1 : Second motor
0x0324
V1
0.01
%
Analog voltage input
0x0325
I
0.01
%
Analog current input
0x0328
AO
0.01
%
Analog output
0x0330
Latch type
trip information-1
-
-
B15
: Reserved
B14
: OHT
B13
: OC2
B12
: EXT
B11
: OVT
B10
: OCT
B9
: NTC
B8
: Reserved
B7
: Reserved
B6
: COL
B5
: POT
B4
: GFT
B3
: ETH
B2
: IOLT
B1
: Reserved
B0
: OLT
0x0331
Latch type
trip information-2
-
-
Others : Reserved
B3 : FAN
0x0332
Latch type
trip information-3
-
-
Others : Reserved
B2 : Lost command B1 : LVT
B0 : BX
0x0333
H/W diagnosis trip
information
-
-
Others : Reserved
B0 : HW-diag
0x0334
Warning
-
Others : Reserved
B4 : FAN working B2 : Inverter overload
B0 : Overload
Address
Parameter
Scale
Unit
Allotment for Bits
0x0380
Frequency
command(Note1)
0.01
Hz
Command frequency setting
0x0381
RPM
command(Note1)
1
rpm
Command RPM setting
0x0382
Operating
command(Note2)
-
-
Others : Reserved
B3 : Free run stop (0->1) B2 : Trip reset (0->1)
B1 : Reverse command (0), Forward command (1)
B0 : Stop command (0), Run command (1)
0x0383
Acceleration time
0.1
sec
Acceleration time setting
0x0384
Deceleration time
0.1
sec
Deceleration time setting
0x0388
PID
reference(Note3)
0.1
%
PID reference command released
0x0389
PID feedback
value(Note4)
0.1
%
PID feedback value
