LSIS sv-ig5a User Manual

11-9
2) Extended Common Area :
2.1) Inverter Monitoring Area Parameters (Reading Only)
Address
Parameter
Scale
Unit
Allotment for Bits
0x0300
Inverter Model
-
-
iG5A : 0x000A
0x0301
Inverter capacity
-
-
0.4kW : 0x0019
0.75kW : 0x3200
1.5kW : 0x4015
2.2kW : 0x4022
3.7kW : 0x4037
4.0kW : 0x4040
5.5kW : 0x4055
7.5kW : 0x4075
11kW : 0x40B0
15kW : 0x40F0
18.5kW : 0x4125
22kW : 0x4160
0x0302
Inverter input
voltage /power
supply type
(1-phase, 3-phase)
/ cooling method
-
-
200V single phase open air cooling : 0x0220
200V 3 phase open air cooling : 0x0230
200V single phase forced cooling : 0x0221
200V 3 phase forced cooling : 0x0231
400V single phase open air cooling : 0x0420
400V 3 phase open air cooling : 0x0430
400V single phase forced cooling : 0x0421
400V 3 phase forced cooling : 0x0431
0x0303
S/W version
-
-
(Ex) 0x0023 : Version 2.3
0x0305
Inverter operating
status
-
-
B15, B14, B13, B12 :
0 : Normal status, 8 : Fault status
B11, B10, B9, B8 : Reserved
B7, B6, B5, B4 :
1 : Speed search, 2 : Accelerating
3 : Steady speed, 4 : Decelerating
5 : Decelerating stop 6 : H/W OCS
7 : S/W OCS 8 : Dwell operating
B3, B2, B1, B0 :
0 : Stop 1 : Forward operating
2 : Reverse operating 3 : DC operating
0x0306
Inverter operating,
frequency
command source
-
-
B15 ~ B8 : Operating command source
0 : Keypad 1 : Reserved
2 : Reserved 3 : Built-in 485
4 : Terminal
B7 ~ B0 : Frequency command source
0 : Keypad 1 : Reserved
2~4 : Up/Down operating speed
5 : V1 6 : I
7 : Built-in 485
26~32 : Multi-step frequency 1~7
0x0310
Output current
0.1
A
-
0x0311
Output frequency
0.01
Hz
-
0x0312
Output RPM
1
RPM
-
0x0314
Output voltage
1
V
-
0x0315
DC Link voltage
1
V
-
0x0316
Output power
0.1
kW
-
0x0318
PID reference
0.1
%
-
0x0319
PID feedback
0.1
%
-
0x031A
Poles of motor
-
-
-
