Note 1) The changed value in Common area affects the current setting but returns to the previous
setting when power is cycled or Inverter is reset. However, changing value is immediately reflected
in other parameter groups even in the case of Reset or Power On/Off.
Note 2) S/W version of Common area is displayed in Hexadecimal, while that of parameter area is
displayed in decimal.
Note 3) User can register up to Read address 8 ea/Write address 8 ea of discontinuous addresses
and read/write them n data(s) with one Read/Write command. Input/Output group I66 through I73
are registered in the common read addresses 0x0100 through 0x0107 and it can be read the
discontinuous n data(s) (less than 8 ea) with a read command. Input/Output group I74 through I81
are registered in the common write addresses 0x0108 through 0x010F and it can be written
discontinuous n data(s) (less than 8 ea) with a write command.
B15, B14, B13, B12, B11, B10, B9, B8 : Reserved
Value corresponding to 0 ~ + 10V input
Value corresponding to 0 ~ - 10V input when setting
Freq Mode to 2
Value corresponding to 0 ~ 20mA input
Writes feedback amount when feedback is set by
communication in PID drive.
Motor output torque display
Read address
register (Note3)
0x0100 : I66 0x0101 : I67
0x0102 : I68 0x0103 : I69
0x0104 : I70 0x0105 : I71
0x0106 : I72 0x0107 : I73
Write address
register (Note3)
0x0108 : I74 0x0109 : I75
0x010A : I76 0x010B : I77
0x010C : I78 0x010D : I79
0x010E : I80 0x010F : I81
