5-2
 Drive Group
LED
display
Address
for
communi
cation
Parameter
name
Min/
Max
range
Description
Factory
defaults
Adj.
during
run
Page
vOL
A10B
[User
display
select]
This parameter displays the item selected at
H73- [Monitoring item select].
vOL
-
9-2
vOL
Output voltage
POr
Output power
tOr
Torque
nOn
A10C
[Fault
Display]
Displays the types of faults, frequency and
operating status at the time of the fault
-
-
9-4
drC
A10D
[Direction
of motor
rotation
select]
F, r
Sets the direction of motor rotation when drv -
[Drive mode] is set to either 0 or 1.
F
O
7-8
F
Forward
r
Reverse
drv2
A10E
[Drive
mode 2]
0 ~ 4
0
Run/Stop via Run/Stop key on the keypad
1
X
8-24
1
Terminal
operation
FX: Motor forward run
RX: Motor reverse run
2
FX: Run/Stop enable
RX: Reverse rotation select
3
RS-485 communication
4
Set to Filed Bus Communication
3)
Frq2
1)
A10F
[Frequency
setting
method 2]
0 ~ 9
0
Digital
Keypad setting 1
0
X
8-24
1
Keypad setting 2
2
Analog
V1 1: -10 ~ +10 [V]
3
V1 2: 0 ~ +10 [V]
4
Terminal I: 0 ~ 20 [mA]
5
Terminal V1 setting 1 +
Terminal I
6
Terminal V1 setting 2+
Terminal I
7
RS485 communication
8
Digital Volume
9
Set to Filed Bus Communication
3)
rEF
2)
A110
PID control
standard
value
setting
0~400
[Hz] or
0~100
[%]
If H58 is 0, it is expressed as a [Hz] unit.
If H58 is 1, it is expressed as a [%] unit.
In [Hz] unit, you can‟t set Max. frequency
more than (F21).
In [%] unit, 100% means Max. frequency.
0.00
0
8-11
Fbk
2)
A111
PID control
feedback
amount
It indicates a feedback amount in PID
control.
If H58 is 0, it is expressed as a [Hz] unit.
If H58 is 1, it is expressed as a [%] unit.
-
-
8-11
1)
: Only displayed when one of the Multi-function input terminals 1-8 [I17~I24] is set to “22”.
2)
: It is indicated when H49(PID control selection) is 1.
3)
: This function can be available with iG5A Communication Option Module.
