LSIS sv-ig5a User Manual

5-3
 Function group 1
LED
display
Address
for
communi
cation
Paramet
er name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
Page
F 0
A200
[Jump
code]
0 ~ 71
Sets the parameter code number to jump.
1
O
4-5
F 1
A201
[Forwar
d/
Reverse
run
disable]
0 ~ 2
0
Fwd and rev run enable
0
X
7-10
1
Forward run disable
2
Reverse run disable
F 2
A202
[Accel
pattern]
0 ~ 1
0
Linear
0
X
7-15
F 3
A203
[Decel
pattern]
1
S-curve
F 4
A204
[Stop
mode
select]
0 ~ 3
0
Decelerate to stop
0
X
7-20
1
DC brake to stop
2
Free run to stop
3
Power Braking stop
8-26
F 8
1)
A208
[DC
Brake
start
frequen
cy]
0.1 ~ 60
[Hz]
This parameter sets DC brake start
frequency.
It cannot be set below F23 - [Start
frequency].
5.00
X
8-1
F 9
A209
[DC
Brake
wait
time]
0 ~ 60
[sec]
When DC brake frequency is reached,
the inverter holds the output for the
setting time before starting DC brake.
0.1
X
F10
A20A
[DC
Brake
voltage]
0 ~ 200
[%]
This parameter sets the amount of DC
voltage applied to a motor.
It is set in percent of H33 – [Motor rated
current].
50
X
F11
A20B
[DC
Brake
time]
0 ~ 60
[sec]
This parameter sets the time taken to
apply DC current to a motor while motor
is at a stop.
1.0
X
F12
A20C
[DC
Brake
start
voltage]
0 ~ 200
[%]
This parameter sets the amount of DC
voltage before a motor starts to run.
It is set in percent of H33 – [Motor rated
current].
50
X
8-2
F13
A20D
[DC
Brake
start
time]
0 ~ 60
[sec]
DC voltage is applied to the motor for DC
Brake start time before motor
accelerates.
0
X
F14
A20E
[Time
for
magneti
zing a
motor]
0 ~ 60
[sec]
This parameter applies the current to a
motor for the set time before motor
accelerates during Sensorless vector
control.
0.1
X
8-15
F20
A214
[Jog
frequen
cy]
0 ~ 400
[Hz]
This parameter sets the frequency for
Jog operation.
It cannot be set above F21 – [Max
frequency].
10.00
O
8-3
1)
: Only displayed when F 4 is set to 1 (DC brake to stop).
