 Function group 1
LED
display
Address
for
commu
nication
Parameter
name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
Page
F51
1)
A233
[Electronic
thermal
level for 1
minute]
50 ~ 200
[%]
This parameter sets max current capable of
flowing to the motor continuously for 1 minute.
The set value is the percentage of H33 –
[Motor rated current].
It cannot be set below F52 –[Electronic thermal
level for continuous].
150
0
10-1
F52
A234
[Electronic
thermal
level for
continuous]
50 ~ 150
[%]
This parameter sets the amount of current to
keep the motor running continuously.
It cannot be set higher than F51 – [Electronic
thermal level for 1 minute].
100
0
F53
A235
[Motor
cooling
method]
0 ~ 1
0
Standard motor having cooling fan
directly connected to the shaft
0
0
1
A motor using a separate motor to
power a cooling fan.
F54
A236
[Overload
warning
level]
30 ~ 150
[%]
This parameter sets the amount of current to
issue an alarm signal at a relay or multi-
function output terminal (see I54, I55).
The set value is the percentage of H33- [Motor
rated current].
150
0
10-2
F55
A237
[Overload
warning
time]
0 ~ 30 [Sec]
This parameter issues an alarm signal when
the current greater than F54- [Overload
warning level] flows to the motor for F55-
[Overload warning time].
10
0
F56
A238
[Overload
trip select]
0 ~ 1
This parameter turns off the inverter output
when motor is overloaded.
1
0
10-2
F57
A239
[Overload
trip level]
30 ~ 200
[%]
This parameter sets the amount of overload
current.
The value is the percentage of H33- [Motor
rated current].
180
0
F58
A23A
[Overload
trip time]
0 ~ 60 [Sec]
This parameter turns off the inverter output
when the F57- [Overload trip level] of current
flows to the motor for F58- [Overload trip time].
60
0
1)
: Set F50 to 1 to display this parameter.
