LSIS sv-ig5a User Manual

5-20
 Input/output group
LED
display
Address
for
communic
ation
Parameter
name
Min/Max
range
Description
Factory
default
Adj.
during
run
Page
I25
A419
[Input
terminal
status
display]
BIT
7
BIT
6
BIT
5
BIT
4
BIT
3
BIT
2
BIT
1
BIT
0
-
-
9-3
P8
P7
P6
P5
P4
P3
P2
P1
I26
A41A
[Output
terminal
status
display]
BIT1
BIT0
-
-
9-3
3AC
MO
I27
A41B
[Filtering
time
constant
for Multi-
function
Input
terminal]
1 ~ 15
If the value is set higher, the
responsiveness of the Input terminal is
getting slower.
4
O
-
I30
A41E
[Multi-
Step
frequency
4]
0 ~ 400
[Hz]
It cannot be set greater than F21 – [Max
frequency].
30.00
O
7-7
I31
A41F
[Multi-
Step
frequency
5]
25.00
O
I32
A420
[Multi-
Step
frequency
6]
20.00
O
I33
A421
[Multi-
Step
frequency
7]
15.00
O
I34
A422
[Multi-
Accel time
1]
0~ 6000
[sec]
3.0
O
7-14
I35
A423
[Multi-
Decel
time 1]
3.0
I36
A424
[Multi-
Accel time
2]
4.0
I37
A425
[Multi-
Decel
time 2]
4.0
I38
A426
[Multi-
Accel time
3]
5.0
I39
A427
[Multi-
Decel
time 3]
5.0
I40
A428
[Multi-
Accel time
4]
6.0
I41
A429
[Multi-
Decel
time 4]
6.0
