LSIS XBF-AD04A User Manual

XGB Analog edition manual
4.10.3 If 4-wired sensor is used (connection terminal unit is used)
2* DC 24V external supply terminal to supply
the analog power to module
1* If sensor and compensating wire are
shielded, shield line can be connected to
PE terminal of the module.
B
PE
b
A
*1
Terminal block
24V
24G
*2
4 - 10
