LSIS XBF-AD04A User Manual

XGB Analog edition manual
3 - 2
3.2 Specification
3.2.1 General specifications
Here describes general specification of analog output module.
No.
Item
Specifications
Related
specifications
1
Ambient
temperature
0℃∼+55℃
-
2
Storage
temperature
-25℃∼+70℃
-
3
Ambient
humidity
5 ~ 95%RH (Non-condensing)
-
4
Storage humidity
5 ~ 95%RH (Non-condensing)
-
5
Vibration
resistance
Occasional vibration
-
-
Frequency
Acceleration
Amplitude
How many times
IEC61131-2
5 ≤ f < 8.4 ㎐
-
3.5 ㎜
10 times each
directions
(X, Y and Z)
8.4 ≤ f ≤ 150 ㎐
9.8 ㎨ (1G)
-
For continuous vibration
Frequency
Acceleration
Amplitude
5 ≤ f < 8.4 ㎐
-
1.75 ㎜
8.4 ≤ f ≤ 150 ㎐
4.9 ㎨ (0.5G)
-
6
Shock resistance
 Peak acceleration: 147 m/s
2
(15G)
 Duration: 11ms
 Half-sine, 3 times each direction per each axis
IEC61131-2
7
Noise resistance
Square wave
Impulse noise
AC: ± 1,500V
DC: ± 900V
LSIS standard
Electrostatic
discharge
Voltage : 4kV (contact discharging)
IEC 61131-2,
IEC 61000-4-
2
Radiated
electromagnetic
field noise
80 ~ 1,000 MHz, 10V/m
IEC 61131-2,
IEC 61000-4-
3
Fast transient
/bust noise
Segment
Power supply
module
Digital/analog input/output
communication interface
IEC 61131-2,
IEC 61000-4-
4
Voltage
2kV
1kV
8
Environment
Free from corrosive gasses and excessive dust
-
9
Altitude
Up to 2,000 ms
-
10
Pollution degree
Less than equal to 2
-
11
Cooling
Air-cooling
-
