Chapter 3 Analog Output Module (XBF-DV04A, XBF-DC04A, XBF-DC04B)
3 - 3
3.2.2 Performance specifications
Here describes performance specification of analog output module.
Item
Specification
XBF-DV04A
XBF-DC04A
XBF-DC04B
Analog
output
Type
Voltage
Current
Current
Range
DC 0 ~ 10V
(Load resistance:
2kΩ or more)
DC 4 ~ 20mA
DC 0 ~ 20mA
(Load resistance:
510Ω or less)
DC 0 ~ 1.2mA
(Load resistance:
510Ω or less)
Digital
input
Type
12-bit binary data
Range
Signed value
0 ~ 4000
0 ~ 4000
0 ~ 4000
Unsigned value
-2000 ~ 2000
-2000 ~ 2000
-2000 ~ 2000
Precise value
0 ~ 1000
400 ~ 2000/0 ~ 2000
0 ~ 1,200
Percentile value
0 ~ 1000
0 ~ 1000
0 ~ 1,000
Maximum resolution
2.5㎷ (1/4000)
5㎂ (1/4000)
0.3㎂ (1/4000)
Accuracy
±0.5% or less
Maximum conversion speed
1 ㎳/channel
Absolute maximum output
DC ±15V
DC +25 ㎃
Number of maximum channel
4 channels
Insulation method
Photo-coupler insulation between input terminal and PLC power
(no insulation between channels)
Terminal connected
11-point terminal block
I/O points occupied
Fixed type: 64 points
Max. no. of installation
7 (when using XBM(C)-DxxxS type)
10 (when using XB(E)C-DxxxH type)
Current
consump
tion
Internal (DC 5V)
110mA
110mA
External
(DC 21.6 ~26.4V)
70mA
120mA
Weight
64g
70g
Remark
Offset and gain about analog output range have been set at the factory and the user can change them.
