Chapter 1 General
1 - 3
Here describes about specification of analog module of XGB series.
1.2.1 Analog input
Item
XBF-AD04A
Analog input
range
Type
Voltage
Current
Range
DC 0 ~ 10V
(Input resistance: 1 MΩ min.)
DC 4 ~ 20㎃
DC 0 ~ 20㎃
(Input resistance: 250 Ω)
Digital output
Type
12 bit binary data
Range
Unsigned
value
0 ~ 4000
Signed value
-2000 ~ 2000
Precise value
0 ~ 1000
400 ~ 2000/0 ~ 2000
Percentile
value
0 ~ 1000
Max. resolution
2.5㎷(1/4000)
5㎂(1/4000)
Accuracy
± 0.5% or less
Max. conversion speed
1.5ms/channel
Absolute max. input
DC ±15V
DC +25㎃
No. of output channel
4 channels
Insulation method
Photo-coupler insulation between input terminal and PLC power
(No insulation between channels)
Connection Terminal
11 point terminal block
I/O points occupied
Fixed type: 64 points
Max. number of equipment
7 (when using XBM(C)-DxxxS type)
10 (when using XB(E)C-DxxxH type)
Consumption
current
Inner (DC 5V)
120㎃
External (DC 24V)
62㎃
Weight
64g
Additional function
Filter-processing, average-processing (time, count)
1.2 Specification of Analog Module
