Chapter 12 Thermocouple Input Option Module (XBO-TC02A)
12.14 Troubleshooting
The chapter describes diagnostics and measures in case any trouble occurs during use of
thermocouple input module.
12.14.1 Status in case of error
You can check whether there is error or not according to the module status.
Items Normal Disconnection
Module H/W error
(Heavy error)
Operation
Normal operation
Every function works
Normal operation
Min. temp. is displayed
Module function stops
Measure
−
Checking sensor wiring
Customer service
12.14.2 Stats check of module
Module type, module information, O/S version and module status of thermocouple input module can
be checked through XG5000 system monitoring function.
(1)
Execution sequence
Two routes are available for the execution.
(a) [Monitor] -> [System Monitoring] -> And on the module screen, click the right mouse button to
display [Module Information].
(b) [Monitor] -> [System Monitoring] -> And Double-click the module screen.
(2)
Module information
(a) Module type: shows the information of the module presently installed.
(b) Module information: shows the O/S version information of module.
(c) O/S version: shows the O/S prepared date of module.
12 - 35
