LSIS XBF-AD04A User Manual

XGB Analog edition manual
3 - 8
3.7 Functions of Analog Output Module
Here describes functions of XBF-DV04A/DC04A module.
Function
Details
Operation
channel
1) It sets up Run/Stop of a channel that will operate an analog output.
2) You can save the time of whole operation by stopping unused channels.
The range of
output
1) It sets up the range of an analog output.
2) Analog voltage output module offers one range of output (DC 0 ~ 10V) and
analog current output module offers two (DC 4 ~ 20mA, DC 0 ~ 20mA).
The range of
input data
1) It sets up the range of a digital input.
2) It offers four ranges of a digital input.
The status of
channel output
1) It sets up the output status of a channel when it switches Run to Stop.
2) It offers four types of output status.
