XGB Analog edition manual
(3) Setting temperature display unit
Unit of temperature conversion value can be specified as Celsius/
Fahrenheit.
(4) Setting filter constant
If filter constant is not specified or specified as “0”, relevant channel is not filtered.
(5) Setting scaling
It specifies whether scaling function is used or not.
(6) Disconnection information
It outputs disconnection information of each channel.
— — — — — — — — — — — —
C
H
3
C
H
2
C
H
1
C
H
0
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
Setting Ch0 filter constant (1~99)
Setting Ch1 filter constant (1~99)
Setting Ch2 filter constant (1~99)
Setting Ch3 filter constant (1~99)
— — — — — — — — — — — —
C
H
3
C
H
2
C
H
1
C
H
0
Scaling function is not used
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
Channel 0 disconnection information
(0: normal,1: sensor A disconnection, 2: sensor B disconnection)
Channel 1 disconnection information
(0: normal,1: sensor A disconnection, 2: sensor B disconnection)
Channel 2 disconnection information
(0: normal,1: sensor A disconnection, 2: sensor B disconnection)
Channel 3 disconnection information
(0: normal, 1: sensor A disconnection, 2: sensor B disconnection)
4 - 24
