7) Scaling min. value/scaling max. value
Scaling data
type
Scaling min value Scaling max value
With sign -32768 ~ [scaling max value -1] [scaling min value+1] ~ 32767
Without sign 0 ~ [scaling max value -1] [scaling min value+1] ~ 65535
(h) Constant input
1) In case the user inputs numbers directly like filter constant, if the relevant parameter is
selected, available range is displayed in the bottom.
2) If the number is out of range, error message is displayed.
(If error information shows, it returns to previous status. Set again.)
5 - 26
