LSIS XBF-AD04A User Manual

XGB Analog edition manual
(2) Output Performance Specification
Classification
Output Performance Specification
No. of output channels
2 channels
Analog
Output
Range
Type
Voltage
Current
Range
DC 1 ~ 5V
DC 0 ~ 5V
DC 0 ~ 10V
(Load resistance: 2kΩ min.)
DC 4 ~ 20
㎃
DC 0 ~ 20㎃
(Load resistance: 510 Ω max.)
Output
range shall be specified in user program or I/O
parameters by channel, and selected with external
voltage/current switches.
Digital
Input
Type
12-bit binary data
Value
Range
Unsigned
0 ~ 4000
Signed
-2000 ~ 2000
Precise
Value
100 ~ 500 (DC 1 ~ 5V)
0 ~ 500 (DC 0 ~ 5V)
0 ~ 1000 (DC 0 ~ 10V)
400 ~ 2000 (DC 4 ~ 20㎃)
0 ~ 2000 (DC 0 ~ 20㎃)
Percentile
Value
0 ~ 1000
Max. Resolution
1/4000
1.25㎷ (DC 1~5V, 0~5V)
2.5
㎷
(DC 0~10V)
5㎂ (DC4~20㎃, 0~20㎃)
Precision
±0.5% max.
Max. Conversion Rate
1ms/channel
Max. Absolute Output
DC ±15V
DC 25
㎃
Additional Functions
Channel output status setting function (selectable from previous,
min., mean, max. value outputs)
(3) I/O Common Performance Specification
Classification
I/O Common Performance Specification
Insulation Type
Photo-
coupler isolation between I/O terminal and PLC power
source (no insulation between channels)
I/O Terminals
11 point terminal block
I/O Points
Fixed type: 64 points
Max. No. of Installation
7 units (XBM(C)-DxxxS type)
10 units (XB(E)C-DxxxH type)
Current
Internal (DC 5V)
120mA
External (DC 24V)
130mA
Weight
73g
Power Supply
DC 20.4 ~ 28.8V
Note1) In order to use analog I/O module, the following version is needed.
Main unit Version information
XBM-DxxxS type
V2.4
XBC-DxxxH type
V1.7
XEC-DxxxH type
V1.0
XEC-DxxxS type
V1.0
6 - 4
