LSIS XBF-AD04A User Manual

Chapter 12 Thermocouple Input Option Module (XBO-TC02A)
12.2.2 Performance Specification
Performance specifications are as follows
Items Specification
Number of input channel 2 channels
Type of input sensor
Thermocouple
K / J
type
(JIS C1602-1995)
Range of input
temperature
K type sensor
-200.0
℃
~ 1300.0
℃
(-328.0
℉
~ 2372.0
℉
)
J type sensor
-200.0
℃
~ 1200.0
℃
(-328.0
℉
~ 2192.0
℉
)
Digital output Temp. display unit
16 bit binary data
Displaying down to one decimal place
(K, J, type: 0.1
℃
)
Accuracy
±1.0% or less
Conversion speed
50ms/2chanelles –note1)
Reference
junction
compensation
Auto compensation by RJC sensing (Thermistor)
Compensation amount
±1.0℃
Additional
function
Average process
Count averaging
Alarm
Input disconnection detection
Warming-up time 15 min or above – note2)
Insulation method
Non-insulation between input channels
Non-insulation between input terminal and PLC
main unit
I/O terminal 5-point terminal block
Supply power Internal 5V
I/O occupied points
Fixed type: 64 points
Consumption current(Internal) 50㎃
Weight 20g
Note1) Conversion speed can be delayed because of scan delay per channel by XGB main unit
Note2)
Warming-up time: for stability of measured temperature, 15 min is necessary after power is on.
- In order to use analog input option board, the following version is needed.
Main Unit Version
XBC E type
V1.1 or above
XBC S type
V1.1 or above
XBC SU type
V1.0 or above
XEC E type
V1.0 or above
XEC SU type
V1.0 or above
XG5000
V.3.61 or above
12 - 3
