LSIS XBF-AD04A User Manual

Chapter 13 Analog Input Module (XBF-AD04C)
13.2.2
Performance specifications
Performance specifications are as follows.
Items
Performance specification
Number of channels
4 channels
Analog
input
Type
Voltage
Current
Range
DC 1 ~ 5V
DC 0 ~ 5V
DC 0 ~ 10V
DC -10 ~ 10V
(Input resistance: 1
㏁
min)
DC 4 ~ 20mA
DC 0 ~ 20mA
(Input resistance: 250 Ω)
Current input or Voltage input can be selected through the external
terminal wiring setting.
►In voltage mode, use V+ and COM terminal for the channel.
In current mode, short V+ and COM terminal and then use I+
and COM terminal.
Digital
output
Type
16 bit binary data (Data : 14Bit)
Range
Unsigned
value
0 ~ 16,000
Signed value
-8,000 ~ 8,000
Precise value
1,000 ~ 5,000 (1 ~ 5V)
0 ~ 5,000 (0 ~ 5V)
0 ~ 10,000 (0 ~ 10V)
-10,000 ~ 10,000 (±10V)
4,000 ~ 20,000 (4 ~ 20
㎃
)
0 ~ 20,000 (0 ~ 20㎃)
Percentile
value
0 ~ 10,000
Max. resolution
1/16,000
0.250
㎷
(1 ~ 5V)
0.3125㎷ (0 ~ 5V)
0.625㎷ (0 ~ 10V)
1.250
㎷
(±10V)
1.0
㎂
(4 ~ 20
㎃
)
1.25㎂ (0 ~ 20㎃)
Accuracy
±0.2% or less (When ambient temperature 25℃)
±0.3% or less (When ambient temperature 0 ~ 55
℃
)
Max. conversion speed
1
㎳
/ channel
Absolute max. input
DC ±15V
DC ±30
㎃
Addition
function
Filter
Digital filter(4 ~ 64,000
㎳
)
Average
Time average (4~16,000
㎳
)
Count average (2~64,000times)
Detection alarm
Disconnection(DC 1~5V, DC 4~20
㎃
)
Hold last value
When input signal exceeds the effective range, holds the last
effective value.
Alarm function
When input signal exceeds the effective range,
relevant flag turns on.
Insulation method
Photo-coupler insulation between input terminal and
PLC power (No insulation between channels)
Connection terminal
15 point terminal block
I/O points occupied
Fixed type assignment: 64
Max. attachable number
7ea (when using XBM(C)-DxxxS type)
10ea (when using XB(E)C-DxxxH type)
Consumption
current
Internal (DC 5V)
105mA
External (DC 24V)
100mA
Weight
72g
Module input power
DC 20.4~28.8V
13 - 3
