Chapter14 Analog Output Module (XBF-DV04C/XBF-DC04C)
14.2.2 Performance specifications
Performance specifications are as follows.
Items
Performance specification
XBF-DV04C
XBF-DC04C
Channels
4 channels
Analog
output
range
Type Voltage Current
Range
DC 1 ~ 5V
DC 0 ~ 5V
DC 0 ~ 10V
DC -10 ~ 10V
(Load resistance: 1
㏀
or more)
DC 4 ~ 20㎃
DC 0 ~ 20㎃
(Load resistance: 600Ω or less)
Output ranges are set in user program or I/O parameter per each
channel.
Digital
input
Type
16 bit binary data (Data : 14Bit)
Range
Unsigned
value
0 ~ 16,000
Signed value
-8,000 ~ 8,000
Precise value
1,000 ~ 5,000 (1 ~ 5V)
0 ~ 5,000 (0 ~ 5V)
0 ~ 10,000 (0 ~ 10V)
-10,000 ~ 10,000 (±10V)
4,000 ~ 20,000 (4 ~ 20
㎃
)
0 ~ 20,000 (0 ~ 20㎃)
Percentile
value
0 ~ 10,000
Max. resolution
1/16,000
0.250㎷ (1 ~ 5V)
0.3125㎷ (0 ~ 5V)
0.625㎷ (0 ~ 10V)
1.250
㎷
(±10V)
1.0㎂ (4 ~ 20㎃)
1.25㎂ (0 ~ 20㎃)
Accuracy
±0.2% or less (When ambient temperature is 25
℃
)
±0.3% or less (When ambient temperature is 0 ~ 55
℃
)
Max. conversion speed
1㎳/ channel
Additional function
Setting of channel output status
(Select one among previous, Min, Max value)
Setting of interpolation method
(Linear interpolation, S-type interpolation)
Insulation method
Photo-coupler insulation between output terminal and PLC power
(no insulation between channels)
Terminal connected 11 point terminal
I/O occupied points
Fixed point assignment: 64 points
Max. attachable number
7ea (when using XBM(C)-DxxxS type)
10ea (when using XB(E)C-DxxxH type)
Weight 68g 69g
Consumed
current
Internal (DC 5V)
70mA
External (DC 24V)
160mA
Power Supply
DC 20.4V ~ 28.8V
14 - 3
