XGB Analog edition manual
14.13.3 Check and Measure the breakdown
(1)
RUN LED is turned off.
RUN LED is turned off.
The analog module is installed on
correct position.
Install the analog module correctly.
No
Yes
I/O information is shown in XG5000
software.
Call our near agency or A/S center.
No
Yes
When the abnormal analog input
module is changed into normal one,
it operates well.
Yes
Call our near agency or A/S center.
(2)
RUN LED is flickering.
RUN LED is flickering.
RUN LED is flikering 1s intervals.
Output wiring is disconnected.
(Only for current output.
Make wiring correctly by referring
instructions.
No
Yes
The parameter setting is correct.
(Check 'PUT' )
The operation parameter is error.
Set correctly by referring parameter setting
rules from instructions.
(Check error code)
No
Output channel input value is exceeded.
Enter correct value by referring output range
from instructions.
14 - 40
To Next Page
