Configuring ATM Logical Ports on Frame-based Modules
I/O Modules for ATM Services
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/054-7
I/O Modules for ATM Services
You can configure most ATM logical port types for B-STDX 9000 I/O Modules
(IOMs). Table 4-1 lists supported IOMs and any exceptions.
Table 4-1. I/O Modules for ATM Services
IOM Type ATM Logical Port Support
Frame-based IOMs
8-port Universal I/O
4-port Unchannelized T1
4-port Unchannelized E1
2-port HSSI
10-port DSX-1
ATM UNI DCE
ATM UNI DTE
OPTimum frame trunk
ATM FR NNI
4-port 24 Channel T1
4-port 30 Channel E1
ATM UNI DCE
ATM UNI DTE
ATM-based IOMs
ATM DS3/E3 UNI
12-port ATM T1
12-port ATM E1
ATM UNI DTE
ATM UNI DCE
Direct trunk
OPTimum cell trunk
OPTimum frame trunk
ATM FR NNI
Note: Because the ATM DS3/E3 UNI, 12-port ATM T1
and 12-port ATM E1 cards are not cell- based, you
configure the same logical port attributes as the
frame-based cards.
1-port ATM CS DS3/E3
1-port ATM IWU
OC-3c/STM-1
ATM UNI DCE
ATM UNI DTE
Direct trunk
OPTimum cell trunk
OPTimum frame trunk
ATM FR NNI
