Configuring ATM Logical Ports on Frame-based Modules
Defining ATM UNI DCE/DTE Logical Ports
2. From the Add Logical Port dialog box, select the Administrative tab (Figure 4-5)
and complete the fields as described in Table 4-7.
Figure 4-2. Add Logical Port: Administrative Tab
Template (Optional) Check this box to save these settings as a
template to use again to quickly configure a logical port
with the same options.
Clear the box (default) if you do not wish to save the
settings as a template.
See “Using Templates” on page 2-23 for more
information.
Table 4-6. Add Logical Port: General Tab Fields (Continued)
Field Action/Description
