21-501/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring PNNI Routing
Configuring PNNI Routing
Configuring an ATM NNI Logical Port
You configure PNNI links as ATM NNI logical ports. To configure an ATM NNI
logical port for PNNI:
1. Select the switch to which you want to add a logical port.
2. Expand the instance node for the PPort or subport to which you want to add an
LPort.
The LPorts class node appears under the PPort or subport instance node.
3. Right-click on the LPorts class node and select Add from the pop-up menu.
The Add Logical Port dialog box appears (Figure 21-15).
4. In the LPort Name field, enter a unique alphanumeric name for the logical port.
5. In the LPort Type field, select ATM NNI from the pull-down list.
6. Use the instructions in Table 21-6 to set the logical port attributes.
Table 21-6. Configuring an ATM NNI Logical Port
Use the instructions on To set the
page 3-27 ATM attributes to select the ATM Protocol, PNNI 1.0
page 3-49 ATM FCP attributes (optional)
page 3-59 SVC attributes:
• SVC Connection ID parameters
• SVC parameters
•SVC priorities
• SVC TD limits
•ATM SVC parameters
• Signaling tuning parameters
