Configuring SVC Parameters
Configuring SVC Port Addresses
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0517-63
Defining SVC Port Address Options
1. Select the General tab in the Add/Modify SVC Port Address dialog box
(Figure 17-34).
Figure 17-34. Modify SVC Port Address Dialog Box
2. Complete the fields in the General tab as described in Table 17-14.
Table 17-14. Modify SVC Port Address: General Tab Fields
Field Action/Description
Source Address
Validation
Select this check box to enable validation of the calling party address
against the UNI/NNI port address that received the call setup
message.
Clear the check box to disable validation of the calling party address
against the UNI/NNI port address that received the call setup
message.
Route
Determination
Select this check box to specify that the OSPF protocol use this
address for route determination.
Enable this option to use PVC/PVP termination (see page 18-3).
CUG Termination Selecting this check box indicates that this address is used as part of a
CUG. Incoming and outgoing calls with a calling or called party
address that match this address are subject to CUG security checks.
For more information about CUGs, see Chapter 19, “CUGs.”
