Configuring ATM PVCs
About Redirect PVCs
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0510-35
Defining Redirect PVCs
To configure a redirect PVC between two UNI or NNI logical ports:
1. In the Switch tab, expand the Circuits node.
2. Right-click on the Redirect PVCs node and select Add from the pop-up menu.
The Add Redirect PVC dialog box appears (Figure 10-8).
Figure 10-8. Add Redirect PVC Dialog Box
3. Choose the Select button in the Endpoints field to define the circuit endpoints.
The Select Endpoints dialog box (Figure 10-9 on page 10-36) appears, allowing
you to set the pivot, primary, and secondary endpoints.
Note – Redirect PVCs are not supported on PPP connections.
