Configuring ATM PVCs
About the PVC Tabs
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0510-25
Shaper ID
(B-STDX ATM
CS/IWU endpoint
only)
Choose the Select button to select a traffic shaper for the endpoint.
Select one of the configured shapers in the Select Traffic Shaper
dialog box.
If this circuit carries ATM cell traffic, use the default of None. If this
circuit carries frame relay traffic, select one of the configured
shapers. These shapers correspond to the traffic shapers configured
for the physical port on which this logical port resides.
For information about physical port traffic shaping, see the Switch
Module Configuration Guide for CBX 3500, CBX 500, GX 550, and
B-STDX 9000.
Table 10-4. Add PVC: Traffic Type Tab Fields (Continued)
Field Action/Description
